Notice
Surfsight® Wi-Fi Auxiliary Camera End of Sale in UK/Europe: The Surfsight® Wi-Fi Auxiliary Camera has been discontinued in the UK and Europe. This is due to the new Radio Equipment Directive (RED) 2014/53/EU standards, taking effect on August 1, 2025, which the current model does not meet. We will continue to provide hardware support for Wi-Fi cameras already deployed. As a seamless alternative, our Surfsight® Wired Auxiliary Cameras are still available. These connect directly to a router and your Surfsight® dashcam. You can find more details in Knowledgebase documents DC-ACE-01 and DC-ACE-02.
|
Element |
Description |
|---|---|
|
Mount |
Flush (Rear) |
|
Wi-Fi |
Connects to the dashcam with Wi-Fi 802.11 b/g/n |
|
Micro-SD |
Built-in 64 GB micro-SD card |
|
Lens |
3.3 mm with day and night functionality |
|
Supported resolution |
Up to 1080p, 30 frames per second |
|
Streaming and recording |
720p, 30 frames per second |
|
Field of view |
Horizontal: 106°; vertical: 55.8°; diagonal: 126° Manual angle adjustment |
|
Night view distance |
30 ft (9.14 m) |
|
Waterproof and dustproof |
IP69K |
|
Power |
12V or 24V DC |
|
Power consumption |
200 mA at 12V |
|
Reset button |
Included |
|
Operating environment |
Temperature with infrared on: -4° to 104° F (-20° to 40° C) Temperature with infrared off: -4° to 140° F (-20° to 60° C) Humidity: 20% to 55%, non-condensing |
|
Dimensions |
3.5*1.5*3.5 in (8.9*3.9*8.9 cm) |
|
Weight |
.99 lb (449 grams) |
|
SKU |
SRF-AUX-S51-02P |
|
Accessories |
1 mounting bracket |
